The results are good, the equipment is reliable, cleaning is less time consuming and the automation meets my needs.
Christophe Clain • Réunion
Free-range layer farm fully equipped with VDL Agrotech equipment
Christophe Clain’s, producer of free-range eggs and supplier of “La Ferme du Chemin d’eau”(commercial franchise “Mâtines”) on the beautiful island of Réunion, opted in 2017 for VDL Agrotech equipment for the free-range layer farm of 16 x 72 meters.
The building, with natural light and ventilation, offers housing to 8100 layers and is built on a surface of 4 hectares. The free-range layers are lucky, as they have a view of “Le Grand Blue”, the Indian Ocean and more importantly, the living space meets all legal requirements regarding animal welfare.
Christophe opted for Chainovation, the VDL chain feeding system, to feed the layers. This feeding system is made of high quality, durable material with an A-frame system which includes 3 perch tubes, resulting in a 17 cm of perching space per bird. This system complies perfectly with the European directives regarding the production of free-range eggs.
The complete feeding system, the A-frame system with 3 perches and chain feeding system, is fully automatic winchable. This offers several advantages:
- It is labor-saving as the A-frames don’t have to be removed manually when cleaning the house
- Cleaning and disinfection is much easier as the equipment can be winched to the ideal height
- Less maintenance, as there is reduced risk of breakdown or technical failures since there is no need for disassembly or reassembly
Another technical advantage of the A-frames of VDL Agrotech is that the trough level can be adjusted in the A-frame support. For instance when the hens transfer from the rearing- to production house, the troughs can be set in the lowest position to make it easier for the hens to find the feed.
“After 2 years of experience, I am still very satisfied with my choice. The support and advice of VDL Agrotech during installation and commissioning was great. The results are good, the equipment is reliable, cleaning is less time consuming and the automation meets my needs. VDL Agrotech's expertise and years of experience have paid off”, says Christophe Clain.
Breeder project in Lithuania
Owner: Kaisiadoriu Paukstynas
This complex can be considered one of the most modern of its kind in Europe, and is absolutely unique in the Baltic States. It was built in accordance to the latest breeding standards, and is equipped with the latest technological developments such as computer controlled automatic feeding with daily tube winching, the Matrix male feeding system and automatic separate flushing of the drinking lines.
The complex with its 5 houses, central feed kitchen, administrative unit and central egg collection area provides place for 60.000 broiler breeders.
Breeder project in Saudi Arabia
Al Bayyad Farms
Location: Al Kharj Area Riyadh
Owner: Sheikh Ibrahim Al Sunayyan
Capacity: 30 Broiler Breeder Houses and 8 Layer Breeder Houses
Al Bayyad Farms Project is a Project of total 30 Broiler Breeder Houses and 8 Layer Breeder Houses of 100mX14m each All in All Out system. It is equipped with VDL Agrotech Silos, Flex Auger, Chain Feeding, Nipple Drinking and Diesel heating Systems including all control devices. It is situated at Al Kharj Area 150 Km from Riyadh.
The first phase of 8 Broiler Breeder Houses was Built, installed and commissioned on the 20th of January 2014. The total capacity of the first 8 Houses is 61600 Females and 10% males.
Breeder project in Uzbekistan
Location: Tashkent Region
Owner: LLC Umid
Capacity: 18.000 Broiler Breeders & 105.000 Broilers
Breeder project in Vietnam
Location: Bao Loc
Capacity: Approx. 50.000 broiler breeders
The project site has 2 zones as follow:
1 zone with 2 rearing houses dimensions 115 x 14 m
2 zone with 3 production houses dimensions 115 x 14 m
Design and delivery of total set of poultry equipment by VDL Agrotech in close cooperation with project support from De Heus the Netherlands and Belgabroed Belgium.
The houses are closed houses with automatic controlled forced ventilation/cooling systems and can be monitored from a distance by Internet Connection.
Special designed so called Venturi air inlets to have an easy and also efficient control of the minimum ventilation together with an Orion climate computer system.
Chainovation feeding systems assure an equal and fast feed distribution in both rearing and parentstock houses.
Breeder project in Finland
Capacity: 12.000 birds/ 1.200 males
Recently VDL Agrotech supplied the first broiler breeder houses in Finland, equipped with our new Matrix male feeding system. This first project consists of 2 houses with in total 12000 hens and 1200 males, located in the surroundings of Turku.
These houses have heating tubes at the wall. In the 2 houses there is limited space between the walls and the other feeding systems. That's why a feed trough for the males, mounted against the wall, is the only feeding solution. Matrix is adviced as the best option.
Breeder project in the Netherlands
Owner: Twan and Jeroen Engelen
Capacity: 7 houses, total 110.000 breeder parentstock
This project has been supplied and installed through our dealer Sleegers Farm Equipment. 7 houses at a new site, Dellerweg, Someren, The Netherlands (August 2012). 5 houses at De Hoof. Total 110.000 breeder parentstock on these two sites. This farm is a visiting adress for VDL-Agrotech customers, we can show electrically winched (both cable- and tube) chainfeedingsystems Chainovation, Matrix and Rotrafeed scratchfeeding. Both farms are state of the art with a maximum attention to animal wellfare and health, aswell as a sustainable production by using solarpanels, heatexchangers, reduction of finedust and ammonia and smell.
Breeder project in Bangladesh
Location: Dhaka region
Capacity: 96.000 Breeders
VDL Agrotech supplied 6 complete breeder houses for this project. This project includes 6 production areas which are divided over 3 sheds each shed is constructed as double story building. The houses measure 128 x 15.2 meter and each shed has a capacity of 11.500 birds. Due to the climatic condition in Bangladesh, the combination of tunnel- and natural ventilation was the most appropriate. By winching the sidewall curtains down, there is a natural ventilation process created. When temperatures rise, the ventilation process is switched to tunnel mode. In this mode, the incoming air will be cooled by the U-shaped padcooling system and creates a wind-chill effect for the birds. Through the end gable fens, the air is blown out of the house.
